Centaur

The Centaur digital recorder is a portable seismic acquisition system that consists of a high-resolution 24-bit ADC, a precision GPS clock, and removable storage capabilities. The Centaur is available in both 3- or 6-channel versions, as well as with a high-gain option. Its ease of use simplifies high-performance seismic deployments in both remote and networked environments.

The Centaur now has expandable memory and even lower power requirements. In fact, the 3-channel version requires less than 1 watt with telemetry. The on-board 8GB memory (standard on both 3- and 6-channel) is expandable up to 64GB by adding an internal SD card.

Exceptional Performance

  • Sample rates up to 5000 sps to support geothermal and/or passive seismic data acquisition

  • Ultra-low noise floor for use with high performance broadband seismometers

  • True 24-bit performance in 3- or 6-channel configurations

  • Rugged field enclosure rated for continuous submersion









Easy Deployment & Data Retrieval

  • Multilingual web interface

  • Direct write to MiniSEED archive

  • Removable media via SD card or USB

  • Comprehensive real-time communications, including SEEDLink support

  • Rugged field enclosure rate for continuous submersion

Onboard Data Processing

  • Advanced bandpassed triggering

  • Derived data products, including PGA, PGV,  and PGD

  • Acquisition and data management of high precision GPX data (BINEX)





For specifications please contact sales_mkt@nanometrics.ca





























Centaur 24-bit Digitizer
